New Air-Cooled System CCD Positioning Auto-Focus 200W Jewelry Electronic Mold Repair Precision YAG Fiber Laser Mold Welding
Short Description:
The mold welding spot welder is a specialized welding equipment designed for mold repair and defect correction. It is primarily used to repair cracks, wear, chipping, pinholes, and other issues on mold surfaces. Featuring high precision and low heat input, it is suitable for the maintenance and enhancement of various molds such as plastic molds, hardware molds, and die-casting molds.
- Product name:Industrial-Grade Continuous Laser Machine for Mold Repair Welding
- Laser power:200W
- Laser type:YAG 1064nm
- Cooling System:Water Cooling
- Position:10X microscope with monitor
- Power Supply:220V/50/60HZ 30A
- Certification:ce
- After-sales Service Provided:Online support
- Online support:Online support
- Function:High Stability/Easy to Operate/High Flexibility
Core Functions and Advantages
Precise repair without damaging the base material: Adopting point-to-point pulse welding technology, the welding points are concentrated with a small heat-affected zone, avoiding deformation, annealing, or cracking of the mold base material.
Application Scenarios
Repair of mold production defects: Patching flaws such as edge chipping, scratches, and pinholes during the processing of new molds.
Customization for special needs: Precisely filling tiny defects (above 0.1mm) of precision molds to ensure mold forming accuracy.
